FEATURES

• Industrial Capacity: True 3000-liter fermentation volume, ideal for high-output operations or centralized brewing hubs.

• Cylindroconical Design: Classic 60° cone bottom ensures effective yeast collection and clean product draw-off.

• Full Thermal Control: Dual-zone glycol cooling jackets (cone + cylinder) with reinforced PU insulation for stable temperature control.

• Pressure Fermentation Ready: Rated for fermentation under pressure with overpressure relief, vacuum protection, and glycerin-filled gauge.

• Clean-in-Place (CIP) Compatible: Equipped with rotary spray ball, sanitary ports, and polished welds for fast and effective internal cleaning.

• Top Access & Dry Hopping: Oversized manway allows safe inspection, dry hop additions, and tank sanitation.

• Durable and Customizable: Fully welded legs with adjustable feet; optional carbonation port, sample valve, sight glass, and racking arm available.

Best Suited For

• Large-scale craft breweries or contract brewing facilities

• Integration with 20HL to 30HL brewhouses

• High-volume fermentation of beer, cider, or hard seltzer

• Multi-batch processing for lagering or maturation lines

FAQ – Common Inquiries

Q1: Can I use this fermenter with a fully automated system?
A: Yes, it supports PLC or semi-automated temperature and pressure monitoring with optional sensors.

Q2: Does it come with all valves included?
A: Standard sets include butterfly valves, PRV, vacuum valve, sample valve, and fittings. Add-ons like carbonation ports are available.

Q3: Is insulation customizable?
A: Yes, insulation thickness (usually 100mm PU) can be adjusted depending on ambient temperature and usage.

Q4: Can the tank be designed with multiple outlet options?
A: Certainly. We offer side discharge, standpipe, or dual-outlet racking options.

Q5: Is this tank suitable for cold crashing?
A: Absolutely. It’s designed for low-temp operation with reliable cooling performance and structure integrity.

Order & Shipping Information

• Configuration: Let us know your cellar setup – cone angle, fitting types, and tank height are all customizable.

• Production Lead Time: 45–55 working days for standard builds; expedited service available upon request.

• Shipping: Global delivery with ISPM-certified wooden packaging, complete customs documentation provided.

• Support: Backed by a 1-year warranty, and remote guidance for installation and startup.
